XTL-A5型风力发电机
型号ModelXTL-A5-100WXTL-A5-200WXTL-A5-300WXTL-A5-400W额定功率Ratedpower100W200W300W400W最大功率Max power120W220W320W420W额定电压Nominal voltage12V/24V12V/24V12V/24V24V启动风速(m/s)Start-up wind speed2.0m/s2.0m/s2.0m/s2.0m/s额定风速(m/s)Rated wind speed13m/s13m/s13m/s13m/s安全风速(m/s)Survival
产品特点
技术参数
型号 Model | XTL-A5-100W | XTL-A5-200W | XTL-A5-300W | XTL-A5-400W |
额定功率 Rated power | 100W | 200W | 300W | 400W |
最大功率 Max power | 120W | 220W | 320W | 420W |
额定电压 Nominal voltage | 12V/24V | 12V/24V | 12V/24V | 24V |
启动风速(m/s) Start-up wind speed | 2.0m/s | 2.0m/s | 2.0m/s | 2.0m/s |
额定风速(m/s) Rated wind speed | 13m/s | 13m/s | 13m/s | 13m/s |
安全风速(m/s) Survival wind speed | 35m/s | 35m/s | 35m/s | 35m/s |
主机净重 Top net weight | 6.5kg | 6.8kg | 7.5kg | 8kg |
风轮直径 Wind wheel diameter | 1.1m | 1.15m | 1.2m | 1.3m |
叶片数量 Number of blades | 6/8 | |||
叶片材料 Blades material | 尼龙纤维 Nylon fiber | |||
机身材料 Fuselage material | 压铸铝aluminum alloy | |||
发电机 Generator | 三相交流永磁同步发电机/磁悬浮发电机 Three phase ac permanent magnet generator/Maglev generators | |||
控制系统 Control System | 电磁刹车 electric eddy brake | |||
偏航方式 Yaw Mode | 自动迎风角度 The wind Angle automatically | |||
润滑方式 Lubrication mode | 自润滑 self-lubricating | |||
塔架形式 Tower form | 拉索/独立塔架 | |||
工作温度 Working temperature | -40℃-80℃ | |||
