XTL-B2型风力发电机
型号ModelXTL-B2-700XTL-B2-800额定功率Ratedpower700W800W最大功率Max power730W820W额定电压Nominal voltage24V/48V24V/48V启动风速Start-up wind speed2.5m/s2.5m/s额定风速Rated wind speed11m/s11m/s安全风速Survival wind speed45m/s45m/s主机净重Top net weight20kg21kg风轮直径Wind wheel diameter1.8m1.9m叶
产品特点
技术参数
型号 Model | XTL-B2-700 | XTL-B2-800 |
额定功率 Rated power | 700W | 800W |
最大功率 Max power | 730W | 820W |
额定电压 Nominal voltage | 24V/48V | 24V/48V |
启动风速 Start-up wind speed | 2.5m/s | 2.5m/s |
额定风速 Rated wind speed | 11m/s | 11m/s |
安全风速 Survival wind speed | 45m/s | 45m/s |
主机净重 Top net weight | 20kg | 21kg |
风轮直径 Wind wheel diameter | 1.8m | 1.9m |
叶片数量 Number of blades | 3/5 | |
叶片材料 Blades material | 尼龙纤维 Nylon fiber | |
机身材料 Fuselage material | 压铸铝 aluminum alloy | |
发电机 Generator | 三相交流永磁同步发电机 Three phase ac permanent magnet generator | |
控制系统 Control System | 电磁/风轮偏侧Electromagnet/wind wheel yaw | |
偏航方式 Yaw Mode | 自动迎风角度 The wind Angle automatically | |
润滑方式 Lubrication mode | 自润滑 self-lubricating | |
塔架形式 Tower form | 拉索/独立塔架 | |
工作温度 Working temperature | -40℃～80℃ | |
